The ELK Stack: Elasticsearch, Logstash, and Kibana Explained

Once you’re running more than one or two services — especially containerized ones managed by Kubernetes — logs stop being something you can tail -f on a single server. Pods get rescheduled, containers get replaced, and the logs they wrote disappear with them. The ELK Stack exists to solve exactly this problem: collect logs from everywhere, store them centrally, and make them searchable.

What ELK Actually Stands For

ELK is an acronym for three separate open-source projects, all originally built or stewarded by Elastic, that are commonly deployed together:

• E — Elasticsearch: a distributed search and analytics engine, built on top of Apache Lucene. This is where the data actually lives, indexed for fast full-text search and aggregation.
• L — Logstash: a server-side data processing pipeline that ingests data from many sources simultaneously, transforms/enriches it, and ships it to a destination (usually Elasticsearch).
• K — Kibana: a web UI that sits on top of Elasticsearch, letting humans search, filter, and visualize the data with dashboards and charts.

You’ll also hear the term “Elastic Stack” — that’s the modern rebrand, which adds Beats (lightweight shippers like Filebeat and Metricbeat that forward data with a much smaller footprint than Logstash) into the mix.

How Logs Actually Flow Through the Pipeline

A typical ELK pipeline looks like this:

[App / Server / Container logs]
        |
        v
   Filebeat (lightweight shipper, runs as an agent)
        |
        v
     Logstash (parse, filter, enrich, transform)
        |
        v
   Elasticsearch (index and store)
        |
        v
      Kibana (search, visualize, alert)

1. Collection — Filebeat (or another Beat) tails log files on each host or container and forwards new lines as they’re written, with minimal CPU/memory overhead.

2. Processing — Logstash receives that raw data and applies filters. A classic example is the grok filter, which uses pattern matching to turn an unstructured line like:

   2026-07-20T10:15:32 ERROR OrderService - Failed to charge card for order #48213


   into structured fields: timestamp, log_level, service, message, order_id. Structured data is what makes the next steps possible — you can’t filter or chart on a blob of raw text nearly as well as you can on named fields.

3. Storage & Indexing — Logstash sends the structured event to Elasticsearch, which indexes it so it’s searchable within roughly a second.
4. Search & Visualization — Kibana queries Elasticsearch and renders it: a search bar for ad-hoc queries, dashboards for trends, and alerting rules for anomalies.

A Simple Example Use Case: Centralized Log Search

Imagine you run 15 microservices across a Kubernetes cluster. A customer reports “checkout failed around 10:15 AM” and you need to find out why — but the failure could be in any of five different services.

Without centralized logging, you’d be running kubectl logs against pod after pod, hoping the right Pod hasn’t already been rescheduled and lost its log history.

With ELK in place, you’d instead go to Kibana and run something like:

log_level:ERROR AND @timestamp:[2026-07-20T10:10:00 TO 2026-07-20T10:20:00]

Because every service ships its logs through Filebeat → Logstash → Elasticsearch, this one query searches across all services at once, and returns matching entries with full context — timestamps, service names, request IDs, stack traces — regardless of which Pod originally produced them or whether that Pod still exists. You can pivot straight into a dashboard showing error-rate-by-service over that window, spot that PaymentService had a spike, and drill into just its logs.

Where It Fits in a Real Stack

ELK typically sits alongside your metrics stack (like Prometheus/Grafana) as the “logs” pillar of observability. In a containerized environment, it plugs in like this: applications running as Kubernetes Pods write logs to stdout, a Filebeat DaemonSet collects those logs from every node, Logstash enriches them, and Elasticsearch/Kibana make them queryable for debugging and alerting.

The main trade-off with ELK is operational weight: Elasticsearch clusters need real capacity planning (heap sizing, shard counts, index lifecycle policies), and Logstash pipelines can become a maintenance burden of their own at scale. That operational cost is exactly why some teams choose Graylog instead — a lighter-weight alternative built on the same underlying idea of centralizing and searching logs, but with a different set of trade-offs, covered in the next post.
